| FRAME | Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers. |
| SIZES | S: 380mm / M: 420mm / L: 450mm / XL: 490mm |
| REAR SHOCK | Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
| SHOCK SETTINGS | medium compression, medium rebound, air volume spacer 0.2 |
| FORK | Fox 38 29 Float GRIP Performance, 160mm, e-bike optimized, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload |
| HEADSET | Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing |
| STEM | Onoff Krypton FG 30mm, CNC, 31.8mm barbore |
| HANDLEBAR | Onoff Krypton 1.0 double butted 7075-T6 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
| GRIPS | Onoff Desert, 1lock-on, 135mm |
| SEATPOST | Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm |
| SADDLE | FIZIK Terra Aidon X5 145mm |
| FRONT BRAKE | Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| REAR BRAKE | Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| BRAKE LEVER | Sram DB8, tool reach adjust, lever pivot bushings |
| RIMS | Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes |
| SPOKES | Mavic J-bend double butted, contactless lacing |
| FRONT HUB | Mavic, Boost 15x110mm, IS 6 bolts |
| REAR HUB | Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub |
| FRONT TIRE | Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead |
| REAR TIRE | Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead |
| CRANKSET | Race Face Aeffect ebike, 165mm |
| RINGS | Sram X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD |
| CHAIN | Sram NX Eagle, 12s, Powerlock |
| REAR DERRAILLEUR | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| SHIFT LEVERS | Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click |
| CASSETTE | Sram PG-1230, 11-50T, 12s |
| DERAILLEUR HANGER | Sram UDH |
| WEIGHT | 24,2 kg |
| DISPLAY | Bosch Kiox 500 / Bosch Mini Remote / Bosch System Controller |
| MOTOR | Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM |
| BATTERY | Bosch Powertube 750Wh |
